APTEK Best cable distribution box for business for industrial protocols

APTEK Best cable distribution box for business for industrial protocols

Brand
APTEK
Connector Series
Junction Box
Locking type
Fix Screw
Mounting type
Straight
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

Junction Box provides more extension possiblity to industrial field control. The distribution boxes are available in 4, 6, 8 or 12 ports with either 4 or 5 poles per port. Ther master cable can be configured iva a M23 connector or pre-molded cable on the junction box.


APTEK Best cable distribution box for business for industrial protocols-1




General Information


Connector SerriesJunction Box
Ports8
Locking typeFix screw
Mounting typeStraight
LED Colour
Yellow
Ambient temperature-40℃ ~ +80℃ Fix Installation
Material of body
PBT
Connector insertTPU
Connector contactsBrass with gold plated
Coupling nut/screwBrass with nickel plated
Body Colour
Black or Yellow
Contact resistance≤ 5 mΩ
Rated Voltage with/without LED
10~30V/120V
Rated current
2A per signal, 9A total

IP rating

IP 67 in locked condition
Locking DesignAnti-Vibration
Seal / O - ring:FKM


Electrical data & Mechanical data
ContactsCodingRated currentVoltageWire gauge/sizeCable jacketCable ending & length
A/CD/CAWGmm²
04 pins

APTEK Best cable distribution box for business for industrial protocols-2

A-Coding2A;9A120V

120V

18~220.75~0.34PUR / PVCCustomized cable ending and length
05 pins
APTEK Best cable distribution box for business for industrial protocols-3A-Coding2A;9A120V

120V

18~220.75~0.34PUR / PVCCustomized cable ending and length


Level and performance



APTEK m12 junction box has to go through a broad array of evaluation. It is assessed to meet local and international standards for electrical safety, sanitation, EMC, energy efficiency, and more. Adopting a whole frame casting structure, it's not prone to deform
APTEK cable distribution box involves different manufacturing processes. These processes may include cold stamping, plastic pressing, insulation, resistance welding, and electrical component heat treatment. The product does not generate toom many noises
APTEK m12 junction box is exclusively designed. Many factors have been taken into considerations, from the circuit diagram to PCB CAD design or PCB layout. The human-machine interface makes it easy to operate
The design of APTEK m12 junction box takes advantage of high-tech. Its parts drawing, assembly drawing, arrangement diagram, schematic diagram, and shaft drawing are all available by the mechanical drawing technologies. It helps reduce the risk of injury and improve work safety
APTEK cable distribution box is sophisticatedly designed. Our architects and engineers consider many issues when working with the design, including environmental issues, aesthetic appearance, occupant comfort, and view. Its surfaces can be painted or electroplated with finishes
m12 junction box ensures cable distribution box to be operated on the safe side. With sensors to detect the position in real-time, it guarantees high precision
