The series of M5 circular connector is specially developed for the minuature sendsor market. The connector of 5mm metric size with thread locking mechanism, is one of the smallest connectors in factory automation industry. It is mainly designed for the application of connecting the 5mm factory automation sensors, signal transmission of the industrial measurement camera and electric bicycles.

APTEK Best m5 circular cable mount connectors for business for engineering-1

APTEK Best m5 circular cable mount connectors for business for engineering-2

General Information

Connector Serries	M5
Gender	Female
Locking type	Fix screw
Mounting type	Straight
Standard	IEC 61076-2-105
Ambient temperature	-25℃ ~ +80℃
Connector insert	PA
Connector contacts	Brass with gold plated
Coupling nut/screw	Brass with nickel plated
Insulation resistance	≥100 MΩ
Contact resistance	≤ 5 mΩ
EMI Shielding	Non-Shielded
IP rating	IP 67 in locked condition
Locking Design	Anti-Vibration
Seal / O - ring:	FKM

Electrical data & Mechanical data

Contacts	Coding	Wire termination	Rated current	Voltage		Wire gauge/size		Wire insulation	Cable ending & length
Contacts	Coding	Wire termination	Rated current	A/C	D/C	AWG	mm²	Wire insulation	Cable ending & length
03 pins	A-Coding	Solder Version	1A	60V	60V	26AWG	0.14	PVC	Customized cable ending and length
04 pins	A-Coding	Solder Version	1A	60V	60V	26AWG	0.14	PVC	Customized cable ending and length

Level and performance

z******e

Quality and safety analysis for APTEK m5 circular cable mount connectors is stringently carried out. It is required to go through short circuit analysis, total load inspection, power analysis, insulation test, and electric arc resistant test. It is offered with low dielectric loss

w******h

APTEK m5 circular cable mount connectors meets the required standards. These standards include IEC international safety standard and other compatible standards such as European safety standards. It has high tensile strength and can be deformed without breakage

a******f

Safety check for APTEK m5 circular cable mount connectors is carried out by the QC team during the production. It will be checked for its electrical safety includes input voltage, amperage, anti-surge-current capability, etc. Its robust structure allows it to be used in harsh environments

r******e

APTEK m5 emi shield cable connector meets the requirements of a series of standards. These standards include IEC 60038 (IEC standard voltages), IEC 60076 (Power transformers - ability to withstand short-circuit), etc. It is vacuum-sealed, which can greatly reduce the bulk of the overall cargo

e******y

APTEK m5 emi shield cable connector is required to pass a wide range of tests. They may include an electrical testing, high current bond test, insulation test, leakage current test, and load test. Its working panel is coated with a photo-sensitive epoxy-based ink, which can ensure its insulation resistance

y******e

Superior performance and long service life make the products competitive. The product has dynamic and mechanical stability
