The series of FieldBus cable connectors are desinged to support the industrial protocols including Devicenet, CAN-BUS, Profibus, Profinet, EtherCAT cable ...

APTEK female ethernet connectors factory for packaging machine-1

General Information

Connector Serries	FieldBus
Gender	Male
Locking type	Fix screw
Mounting type	Straight
Connector	M12 Male, RJ45 CAT 5E
Ambient temperature	-25℃ ~ +80℃
Connector overmold	TPE/ TPU
Connector insert	PA
Connector contacts	Brass with gold plated
Coupling nut/screw	Brass with nickel plated
Insulation resistance	≥100 MΩ
Contact resistance	≤ 5 mΩ
EMI Shielding	Shielded
IP rating	IP 67 in locked condition
Locking Design:	Anti-Vibration
Seal / O - ring:	FKM

Electrical data & Mechanical data

Contacts	Available Coding		Rated current	Voltage	Wire gauge/size			Cable jacket	Wire insulation	Wiring list	Cable ending & length
Contacts	A	D	Rated current	A/C	D/C	AWG	mm²	Cable jacket	Wire insulation	Wiring list	Cable ending & length
04 pins			4A	250V	250V	24AWG	0.34	PVC	HDPE	1.BN brown 2.WH white 3.BU blue 4.BK black	Customized cable ending and length
08 pins			2A	30V	30V	26AWG	0.25	PVC	HDPE	1.BN brown 2.WH white 3.BU blue 4.BK black 5.GY grey 6.PK pink 7.BU blue 8.RD red	Customized cable ending and length

Level and performance

k******y

Each step is strictly monitored by the professional quality inspection department. A continuous inspection system is implemented to ensure the high quality of this product. This product has a high level of insulation

f******t

The adoption of advanced equipment and the lean production method make APTEK ethernet connectors more cost-effective. Its shape can be customized according to needs

m******t

The source of raw materials: before APTEK ethernet cable assembly comes out, it is processed from high quality raw materials. These materials are sourced from several different places within and out of the region. This product can repeat the same measurement many times

a******r

APTEK ethernet connectors is manufactured with accuracy in specifications. Since it is maintenance-free, this product significantly helps save operation costs

h******y

Strong designer team: APTEK ethernet cable assembly is designed by our design team who are powerful with professional design knowledge. They are also well-trained to put forward design concept and complete the design in a short time. It works stably under strong impact and vibration conditions

h******i

It has a low fabric shrinkage rate. The fabric has been treated under steam or atomizing, extruded by machine, and dried, which makes the shrinkage rate drop to 1% or lower. Since it is maintenance-free, this product significantly helps save operation costs
