The series of M5 circular connector is specially developed for the minuature sendsor market. The connector of 5mm metric size with thread locking mechanism, is one of the smallest connectors in factory automation industry. It is mainly designed for the application of connecting the 5mm factory automation sensors, signal transmission of the industrial measurement camera and electric bicycles.

APTEK male connector m5 factory for industry-1

APTEK male connector m5 factory for industry-2

General Information

Connector Serries	M5
Gender	Female
Locking type	Fix screw
Mounting type	Straight
Standard	IEC 61076-2-105
Ambient temperature	-25℃ ~ +80℃
Connector insert	PA
Connector contacts	Brass with gold plated
Coupling nut/screw	Brass with nickel plated
Insulation resistance	≥100 MΩ
Contact resistance	≤ 5 mΩ
EMI Shielding	Non-Shielded
IP rating	IP 67 in locked condition
Locking Design	Anti-Vibration
Seal / O - ring:	FKM

Electrical data & Mechanical data

Contacts	Coding	Wire termination	Rated current	Voltage		Wire gauge/size		Wire insulation	Cable ending & length
Contacts	Coding	Wire termination	Rated current	A/C	D/C	AWG	mm²	Wire insulation	Cable ending & length
03 pins	A-Coding	Solder Version	1A	60V	60V	26AWG	0.14	PVC	Customized cable ending and length
04 pins	A-Coding	Solder Version	1A	60V	60V	26AWG	0.14	PVC	Customized cable ending and length

Level and performance

k******l

In terms of surface finishes, APTEK connector m5 provide all possible options. The surface treatment is available in a variety of ways. This product is widely used in the fields of industrial packaging, offices, advertising, shipping, etc

p******p

The design of APTEK connector m5 is very practical. It is carefully designed according to the size, weight, and characteristics of the product to be packaged. It will not lose its adherence force even stored for a long period

z******p

APTEK connector m5 has an excellent design. It is designed by our experts with the highest quality materials and finishes. This product can keep the packaged contents safe and secured

e******v

The design of APTEK m5 non-shielded cable connectors innovative. It is implemented by a team of designers who adopted their unique concepts of color, font, and appearance. The product has a super clear backing to show the brand logo

n******s

APTEK m5 non-shielded cable connectors has a good design. It is made by our professional designers using the finest materials and finishes. Its rolling end face is very smooth and neat

o******n

The product is not prone to oxidization. Through an electrical process to form a certain layer of an anodic layer on its surface, it is not affected by the air or moisture. It will not lose its adherence force even stored for a long period
