The series of M5 circular connector is specially developed for the minuature sendsor market. The connector of 5mm metric size with thread locking mechanism, is one of the smallest connectors in factory automation industry. It is mainly designed for the application of connecting the 5mm factory automation sensors, signal transmission of the industrial measurement camera and electric bicycles.

APTEK Top circular connectors factory for engineering-1

APTEK Top circular connectors factory for engineering-2

General Information

Connector Serries	M5
Gender	Female
Locking type	Fix screw
Mounting type	Straight
Standard	IEC 61076-2-105
Ambient temperature	-25℃ ~ +80℃
Connector insert	PA
Connector contacts	Brass with gold plated
Coupling nut/screw	Brass with nickel plated
Insulation resistance	≥100 MΩ
Contact resistance	≤ 5 mΩ
EMI Shielding	Non-Shielded
IP rating	IP 67 in locked condition
Locking Design	Anti-Vibration
Seal / O - ring:	FKM

Electrical data & Mechanical data

Contacts	Coding	Wire termination	Rated current	Voltage		Wire gauge/size		Wire insulation	Cable ending & length
Contacts	Coding	Wire termination	Rated current	A/C	D/C	AWG	mm²	Wire insulation	Cable ending & length
03 pins	A-Coding	PCB Version	1A	60V	60V	26AWG	0.14	PVC	Customized cable ending and length
04 pins	A-Coding	PCB Version	1A	60V	60V	26AWG	0.14	PVC	Customized cable ending and length

Level and performance

x******e

APTEK circular connectors meets the requirements of some necessary certifications. They may include CB certification, CCC certification, CCA certification, and LOVAG certification.

s******j

The design of APTEK circular connectors covers many factors. They mainly include statics and dynamics effect, parts tolerances and deformation, size stability, etc.

d******b

APTEK circular connectors is manufactured in line with high-quality standards. It is produced with excellent anti-corrosive, anti-static, water-resistant, and dust-proof performance.

t******c

The necessary tests on APTEK m5 female cable connector must be conducted. It has passed EMF (electromagnetic fields) tests according to EN 62233, environmental tests (climatic, impact, vibrations, IP rating), and on-site tests.

q******l

A series of tests for APTEK m5 female cable connector is necessary. It has been tested in terms of voltage compatibility, electromagnetic safety, frequency stability, and plug safety.

m******z

It has satisfactory durability. Fabric and weaving techniques were selected based on the specific use of the product.
