The series of M5 circular connector is specially developed for the minuature sendsor market. The connector of 5mm metric size with thread locking mechanism, is one of the smallest connectors in factory automation industry. It is mainly designed for the application of connecting the 5mm factory automation sensors, signal transmission of the industrial measurement camera and electric bicycles.

APTEK Wholesale m5 circular connector manufacturers for industry-1

APTEK Wholesale m5 circular connector manufacturers for industry-2

General Information

Connector Serries	M5
Gender	Male
Locking type	Fix screw
Mounting type	Straight
Standard	IEC 61076-2-105
Ambient temperature	-25℃ ~ +80℃
Connector insert	PA
Connector contacts	Brass with gold plated
Coupling nut/screw	Brass with nickel plated
Insulation resistance	≥100 MΩ
Contact resistance	≤ 5 mΩ
EMI Shielding	Non-Shielded
IP rating	IP 67 in locked condition
Locking Design	Anti-Vibration
Seal / O - ring:	FKM

Electrical data & Mechanical data

Contacts	Coding	Wire termination	Rated current	Voltage		Wire gauge/size		Wire insulation	Cable ending & length
Contacts	Coding	Wire termination	Rated current	A/C	D/C	AWG	mm²	Wire insulation	Cable ending & length
03 pins	A-Coding	Solder Version	1A	60V	60V	26AWG	0.14	PVC	Customized cable ending and length
04 pins	A-Coding	Solder Version	1A	60V	60V	26AWG	0.14	PVC	Customized cable ending and length

Level and performance

f******a

The electric performance test of APTEK m5 circular connector is conducted at the quality inspection stage. The main electrical performance index such as capacity, internal resistance, lifespan, and short circuit protection will be tested by the QC team. It has obtained the certifications of CE, RoHS, EMC, LVD, etc

u******j

APTEK m5 circular connector is of flexible design. It is created by our designers who understand elements of design and use them in different ways to produce different kinds of art/objects and visual effects. Even if it is frequently switched, its service life won't be affected

b******i

APTEK m5 female cable connector is shipped with a professional transport package. Full-round protection foam and high-quality carton or wooden box will be used to protect such fragile sanitary ware. It is available in different wattages

g******z

APTEK m5 circular connector has to go through the necessary tests. It has been tested in terms of strength, ductility impact resistance, hardness, and fracture toughness. The product has low power consumption and high brightness

r******t

APTEK m5 female cable connector has passed various tests conducted by the QC team. It is strictly inspected to ensure its specifications fit specific phone models. The product is environmental-friendly, meeting the requirements of sustainable living

y******b

The design of the product is eye-catching. It aims to let the packaged items being noticed by the customers. The product features quick and easy installation
