1. The advanced technology has been applied throughout the whole production of APTEK m8 panel mount connector . The modern industrial production at APTEK has increased safety, reliability, and rapid installation
2. The adoption of m8 circular cable connector method can cause custom m8 cable connector and satisfy production requirements. APTEK is a focus on industrial connectors for nearly 10 years
3. Zhongshan Aptek Electronics Technology Co.,Ltd According to the actual development needs of the enterprise, an effective cost control system has been established. Not only has a reasonable budget been formulated for each link of product production, but also insists on regular monitoring and inspection of the production status of products, and timely correction of problems found. Fundamentally control the production cost, so that the produced m8 panel mount connector has a more prominent price advantage compared with similar products.
4. Zhongshan Aptek Electronics Technology Co.,LtdAdopt scientific management methods to organize production activities, strictly control the quality in each important link of production, strictly control production costs, and ensure that the produced m8 panel mount connector are of high quality, affordable, and cost-effective far exceeding other similar products.

The series of M8 circular connector provides a wide range of metric M8 connectors for small sensors and actuators. The connector of 8mm metric size with thread locking mechanism, is one of the most commonly used connectors in factory automation, ideally suited for industrial control networks where small sendos are required.

APTEK lead m8 panel mount connector company for engineering-1

APTEK lead m8 panel mount connector company for engineering-2

General Information

Connector Serries	M8
Gender	Female
Locking type	Fix screw
Mounting type	Straight / Right angled
Standard	IEC 61076-2-104
Ambient temperature	-20℃ ~ +80℃
Connector overmold	TPE/ TPU
Connector insert	PA
Connector contacts	Brass with gold plated
Coupling nut/screw	Brass with nickel plated
Insulation resistance	≥100 MΩ
Contact resistance	≤ 5 mΩ
EMI Shielding	Non-Shielded
IP rating	IP 67 in locked condition
Locking Design	Anti-Vibration
Seal / O - ring:	FKM

Electrical data & Mechanical data

Contacts	Coding	Rated current	Voltage		Wire gauge/size		Cable jacket	Wire insulation	Wiring list	Cable ending & length
Contacts	Coding	Rated current	A/C	D/C	AWG	mm²	Cable jacket	Wire insulation	Wiring list	Cable ending & length
03 pins	A-Coding	3A	60V	60V	24AWG	0.25	PUR / PVC	PVC	1.BN brown 3.BU blue 4.BK black	Customized cable ending and length
04 pins	A-Coding	3A	30V	30V	24AWG	0.25	PUR / PVC	PVC	1.BN brown 2.WH white 3.BU blue 4.BK black
05 pins	B-Coding	3A	30V	30V	24AWG	0.25	PUR / PVC	PVC	1.BN brown 2.WH white 3.BU blue 4.BK black 5.GY grey
06 pins	A-Coding	1A	30V	30V	26AWG	0.14	PUR / PVC	PVC	1.BN brown 2.WH white 3.BU blue 4.BK black 5.GY grey 6.PK pink
08 pins	A-Coding	1A	30V	30V	26AWG	0.14	PUR / PVC	PVC	1.WH white 2.BN brown 3.GN green 4.YL yellow 5.GY grey 6.PK pink 7.BU blue 8.RD red

Level and performance

Company Features
1. The manufacturing capabilities of Zhongshan Aptek Electronics Technology Co.,Ltd m8 panel mount connector are widely recognized. Designated as a national fixed-point m8 circular connector units, Zhongshan Aptek Electronics Technology Co.,Ltd has a strong technological base and manufacturing capacity.
2. One of the most important advantages lies in our high quality for m8 sensor connectors.
3. The m8 circular metric connectors is manufactured by our high technology and experienced employees. We always keep professionalism in every production process of m8 connectors . Please contact.

j******i

APTEK m8 connectors has to go through a broad array of evaluation. It is assessed to meet local and international standards for electrical safety, sanitation, EMC, energy efficiency, and more. Featuring high automation, it helps reduce labor intensity

p******b

APTEK m8 circular connector involves different manufacturing processes. These processes may include cold stamping, plastic pressing, insulation, resistance welding, and electrical component heat treatment. It contributes greatly to increasing the yield of merchandise, improving the profits of customers

s******w

APTEK m8 circular connector is exclusively designed. Many factors have been taken into considerations, from the circuit diagram to PCB CAD design or PCB layout. The product can achieve high-speed running

p******c

The design of APTEK m8 connectors takes advantage of high-tech. Its parts drawing, assembly drawing, arrangement diagram, schematic diagram, and shaft drawing are all available by the mechanical drawing technologies. This product stands up to repetitive machining operations

z******a

APTEK m8 circular metric connectors is sophisticatedly designed. Our architects and engineers consider many issues when working with the design, including environmental issues, aesthetic appearance, occupant comfort, and view. The product features a high automation level, which helps reduce labor costs

j******d

m8 panel mount connector ensures m8 panel mount connector to be operated on the safe side. It contributes greatly to increasing the yield of merchandise, improving the profits of customers
