The series of M8 circular connector provides a wide range of metric M8 connectors for small sensors and actuators. The connector of 8mm metric size with thread locking mechanism, is one of the most commonly used connectors in factory automation, ideally suited for industrial control networks where small sendos are required.

APTEK panel m8 field wireable connector suppliers for engineering-1

APTEK panel m8 field wireable connector suppliers for engineering-2

General Information

Connector Serries	M8
Gender	Male
Locking type	Fix screw
Mounting type	Straight / Right angled
Standard	IEC 61076-2-104
Ambient temperature	-20℃ ~ +80℃
Connector overmold	TPE/ TPU
Connector insert	PA
Connector contacts	Brass with gold plated
Coupling nut/screw	Brass with nickel plated
Insulation resistance	≥100 MΩ
Contact resistance	≤ 5 mΩ
EMI Shielding	Shielded
IP rating	IP 67 in locked condition
Locking Design	Anti-Vibration

Electrical data & Mechanical data

Contacts	Coding	Rated current	Voltage		Wire gauge/size		Cable jacket	Wire insulation	Wiring list	Cable ending & length
Contacts	Coding	Rated current	A/C	D/C	AWG	mm²	Cable jacket	Wire insulation	Wiring list	Cable ending & length
03 pins	A-Coding	3A	60V	60V	24AWG	0.25	PUR / PVC	PVC	1.BN brown 3.BU blue 4.BK black	Customized cable ending and length
04 pins	A-Coding	3A	30V	30V	24AWG	0.25	PUR / PVC	PVC	1.BN brown 2.WH white 3.BU blue 4.BK black
05 pins	B-Coding	3A	30V	30V	24AWG	0.25	PUR / PVC	PVC	1.BN brown 2.WH white 3.BU blue 4.BK black 5.GY grey
06 pins	A-Coding	1A	30V	30V	26AWG	0.14	PUR / PVC	PVC	1.BN brown 2.WH white 3.BU blue 4.BK black 5.GY grey 6.PK pink
08 pins	A-Coding	1A	30V	30V	26AWG	0.14	PUR / PVC	PVC	1.WH white 2.BN brown 3.GN green 4.YL yellow 5.GY grey 6.PK pink 7.BU blue 8.RD red

Level and performance

y******e

APTEK m8 field wireable connector is produced using optimum quality materials which we source from trusted vendors of the market. It embodies the most advanced materials and technology exclusively adopted by Unique Group that have ever been found on the market

j******f

The materials employed in the production of APTEK m8 circular cable connector is up to the international standard. It can be used for various engineering purposes, such as buildings, roads, and bridges

p******c

m8 circular cable connector is unusual in design and appropriate in size. It can be manufactured upon our on-site surveying, which ensures that it suits the needs of your project

b******j

The raw materials of APTEK m8 circular cable connector mainly comes from licensed suppliers. It has an anti-abrasion spraying coat, which improves its long term abrasion performance

h******q

APTEK m8 circular cable connector is made with advanced production equipment and fine production technology. It produces much less noise when compared with its equivalents on the market and thus is suitable for overnight use

d******y

m8 field wireable connector Selected high-quality materials are manufactured using cutting-edge technologies and processes in the industry. They have good performances such as shock resistance, drop resistance, water and dust resistance, wear resistance and compression resistance. They are durable and have a long service life.
