APTEK emishielded m8 sensor connectors manufacturers for packaging machine

APTEK emishielded m8 sensor connectors manufacturers for packaging machine

Connector Series
M8
Locking type
Fix screw
Mounting type
Straight
Standard
IEC 61076-2-104
Connector overmold
PA + GF
Coupling nut/screw
Brass with nickel plated
Locking Design
Anti-Vibration
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

The series of M8 circular connector provides a wide range of metric M8 connectors for small sensors and actuators. The connector of 8mm metric size with thread locking mechanism, is one of the most commonly used connectors in factory automation, ideally suited for industrial control networks where small sendos are required.


APTEK emishielded m8 sensor connectors manufacturers for packaging machine-1
APTEK emishielded m8 sensor connectors manufacturers for packaging machine-2



General Information


Connector SerriesM8
GenderMale
Locking typeFix screw
Mounting typeStraight
StandardIEC 61076-2-104
Ambient temperature-25℃ ~ +80℃
Connector overmoldPA + GF
Connector insertPA + GF
Connector contactsBrass with gold plated
Coupling nut/screwBrass with nickel plated
Insulation resistance≥100 MΩ
Contact resistance≤ 5 mΩ
EMI ShieldingNon-Shielded
Suitable cable Dia:3.5 ~ 5.0mm
IP rating:IP 67 in locked condition
Locking Design:Anti-Vibration


Electrical data & Mechanical data


ContactsCodingRated currentVoltageWire gauge/sizeWire insulationCable ending & length
A/CD/CAWGmm²
03 pins

APTEK emishielded m8 sensor connectors manufacturers for packaging machine-3

A-Coding3A60V

60V

22~26AWG0.34~0.14PVCCustomized cable ending and length
04 pins

APTEK emishielded m8 sensor connectors manufacturers for packaging machine-4

A-Coding3A60V60V22~26AWG0.14~0.34PVC


Level and performance



The design of APTEK m8 cable connector manufacturer is of professionalism. It is carried out considering many factors such as mechanical structure, spindles, control system, and part tolerances. The product has passed the environmental-friendly test of CTI
The design processes of APTEK m8 sensor connectors are of professionalism. These processes include recognition of its need or purpose, selection of a possible mechanism, analysis of forces, material selection, design of elements (sizes and stresses), and detailed drawing. It has a maximum service life of over 50,000 hours
APTEK m8 sensor connectors has been tested according to the general standards. It is tested in terms of functionality, strength, stiffness, wears, and corrosion. The product has been certified under CE and RoHS
The design of APTEK m8 sensor connectors is strictly conducted. It is carried out by our designers who think highly of parts and components safety, the whole machine safety, operation safety, and environmental safety. It can improve the power efficiency of electricity
APTEK m8 sensor connectors must go through these following production stages, including metal materials procurement and preparation, components machining, surface polishing, and assembly. The product is popular for its flame-resistant design
The product has long-lasting performance and strong usability. Its ultra capacitance can be up to 330,000uF
