M12 Circular Connector to USB2.0 Connector Molded with Cable

M8 Circular Connector to USB2.0 Connector Molded with Cable

Ethernet Patch Cables, double ended RJ45 8P8C male plug with locking screw on one end

Ethernet Patch Cables, double ended RJ45 8P8C male plug

Product Information
Feedback

Company Advantages
1. m8 cable connector 's membrane cloth is made of high-quality membrane materials and advanced production technology. It is thick in texture and high in quality. It has the functions of sun protection, rain protection, frost protection, and dust protection. The quality is trustworthy.
2. This product caters to the latest market trends and carved a niche in the industry. Fast delivery is a promise of APTEK: only 2 weeks are needed
3. m8 cable connector Selected high-quality raw materials, refined with superb technology and craftsmanship, non-toxic and tasteless, safe and environmentally friendly, strong practicability, reliable quality, and can be used with confidence.
4. m8 cable connector Well-selected materials, stable performance, high quality, guaranteed quality, both aesthetics and practicality, you can buy and use with confidence.

The series of M8 circular connector provides a wide range of metric M8 connectors for small sensors and actuators. The connector of 8mm metric size with thread locking mechanism, is one of the most commonly used connectors in factory automation, ideally suited for industrial control networks where small sendos are required.

Latest m8 cable connector lead manufacturers for industry-1

Latest m8 cable connector lead manufacturers for industry-2

General Information

Connector Serries	M8
Gender	Male
Locking type	Fix screw
Mounting type	Straight
Standard	IEC 61076-2-104
Ambient temperature	-25℃ ~ +80℃
Connector insert	PA
Connector contacts	Brass with gold plated
Coupling nut/screw	Brass with nickel plated
Insulation resistance	≥100 MΩ
Contact resistance	≤ 5 mΩ
EMI Shielding	Non-Shielded
IP rating	IP 67 in locked condition
Locking Design	Anti-Vibration

Electrical data & Mechanical data

Contacts	Coding	Wire termination	Rated current	Voltage		Wire gauge/size		Wire insulation	Cable ending & length
Contacts	Coding	Wire termination	Rated current	A/C	D/C	AWG	mm²	Wire insulation	Cable ending & length
03 pins	A-Coding	Solder Version	3A	60V	60V	24AWG	0.25	PVC	Customized cable ending and length
04 pins	A-Coding	Solder Version	3A	30V	30V	24AWG	0.25	PVC
05 pins	B-Coding	Solder Version	3A	30V	30V	24AWG	0.25	PVC
06 pins	A-Coding	Solder Version	1A	30V	30V	26AWG	0.14	PVC
08 pins	A-Coding	Solder Version	1A	30V	30V	26AWG	0.14	PVC

Level and performance

Company Features
1. APTEK has its own team to help improve the performance of m8 cable connector .
2. We bear social responsibilities. We continually improve our environmental performance and encouraging our suppliers and partners to do the same.

h******k

After years of industry exploration, Zhongshan Aptek Electronics Technology Co.,Ltd has not only accumulated rich production experience, but also mastered advanced production technology, which can realize m8 bulkhead connector good and fast production, and all m8 bulkhead connector have undergone strict quality inspections and meet national standards Quality inspection standards, quality is trustworthy.

m******v

m8 cable connector In the whole production process, there are personnel to inspect, not only that, Zhongshan Aptek Electronics Technology Co.,Ltd also has a testing department, which conducts re-inspection of various performance indicators before m8 cable connector leaves the factory to ensure that m8 cable connector meets the needs and expectations of customers.

x******f

The company always adheres to the production concept of "attitude determines everything, quality comes from details", and implements strict quality management in all aspects of product selection, production, inspection and delivery to ensure that m8 bulkhead connector entering the market are all products of reliable quality .

j******b

Zhongshan Aptek Electronics Technology Co.,Ltd Not only has a complete procurement management system and a rigorous quality control system, but also has mastered various advanced production techniques, and is able to produce m8 cable connector with excellent quality.

a******d

Zhongshan Aptek Electronics Technology Co.,Ltd Relying on years of accumulated production experience, strong technology and research and development strength, advanced equipment and production lines, it is more handy in the production and manufacturing of m8 bulkhead connector, knowing how to reasonably supervise and control each production step and process, Provide guarantee for the production of high-quality products.

i******x

It is well-known for its termite resistance. During the production, it has pre-treated with professional methods such as soaking in the clean water for hours and spraying with an anti-termite agent.
